difficulty to plot an ellipse...

Asked by: JAMET 425
plotting ellipse
August 01 2019
0  4
P; Q; lma; [3 -42] [-, ---] [2 25 ] [22649 -2304] [-----, -----] [5523 1841 ] 1.627112258 with(geometry); point(Pp, P[1], P[2]); point(Qp, Q[1], Q[2]); ellipse(p, ['foci' = [Pp, Qp], 'MajorAxis' = lma]); Error, (in geometry:-ellipse) the given polynomial/equation is not an algebraic representation of a ellipse; I can't understand this error

How to get coordinates of triangle ABC knowing tha...

Asked by: minhthien2016 415
July 28 2019
0  11

I want to find one option of coodiantes of vertices A, B, C of the triangle ABC, knowing that coordinates centre of circumcircle is O(0,0) and length of sides are 3, 5, 7.
How can I get the result?

Numbrix Puzzle by the branch and bound method

by: Kitonum 21575 Maple 2018
branchandbound numbrix-puzzle
July 28 2019
3  3

In this post, the Numbrix Puzzle is solved by the branch and bound method (see the details of this puzzle in  https://www.mapleprimes.com/posts/210643-Solving-A-Numbrix-Puzzle-With-Logic). The main difference from the solution using the  Logic  package is that here we get not one but all possible solutions. In the case of a unique solution, the  NumbrixPuzzle procedure is faster than the  Numbrix  one (for convenience, I inserted the code for Numbrix procedure into the worksheet below). In the case of many solutions, the  Numbrix  procedure is usually faster (see all the examples below).



>

restart;
>

NumbrixPuzzle:=proc(A::Matrix)
local A1, L, N, S, MS, OneStepLeft, OneStepRight, F1, F2, m, L1, p, q, a, b, T, k, s1, s, H, n, L2, i, j, i1, j1, R;
uses ListTools;
S:=upperbound(A); N:=nops(op(A)[3]); MS:=`*`(S);
A1:=convert(A, listlist);
for i from 1 to S[1] do
for j from 1 to S[2] do
for i1 from i to S[1] do
for j1 from 1 to S[2] do
if A1[i,j]<>0 and A1[i1,j1]<>0 and abs(A1[i,j]-A1[i1,j1])<abs(i-i1)+abs(j-j1) then return `no solutions` fi;
od; od; od; od;
L:=sort(select(e->e<>0, Flatten(A1)));
L1:=[`if`(L[1]>1,seq(L[1]-k, k=0..L[1]-2),NULL)];
L2:=[seq(seq(`if`(L[i+1]-L[i]>1,L[i]+k,NULL),k=0..L[i+1]-L[i]-2), i=1..nops(L)-1), `if`(L[-1]<MS,seq(L[-1]+k,k=0..MS-L[-1]-1),NULL)];


OneStepLeft:=proc(A1::listlist)
local s, M, m, k, T;
uses ListTools;
s:=Search(a, Matrix(A1));
M:=[[s[1]-1,s[2]],[s[1]+1,s[2]],[s[1],s[2]-1],[s[1],s[2]+1]];
T:=table(); k:=0;
for m in M do
if m[1]>=1 and m[1]<=S[1] and m[2]>=1 and m[2]<=S[2] and A1[op(m)]=0 then k:=k+1; T[k]:=subsop(m=a-1,A1);
fi;
od;
convert(T, list);
end proc;


OneStepRight:=proc(A1::listlist)
local s, M, m, k, T, s1;
uses ListTools;
s:=Search(a, Matrix(A1));  s1:=Search(a+2, Matrix(A1));
M:=[[s[1]-1,s[2]],[s[1]+1,s[2]],[s[1],s[2]-1],[s[1],s[2]+1]];
T:=table(); k:=0;
for m in M do
if m[1]>=1 and m[1]<=S[1] and m[2]>=1 and m[2]<=S[2] and A1[op(m)]=0 and `if`(a+2 in L, `if`(is(abs(s1[1]-m[1])+abs(s1[2]-m[2])>1),false,true),true) then k:=k+1; T[k]:=subsop(m=a+1,A1);
fi;
od;
convert(T, list);
end proc;

F1:=LM->ListTools:-FlattenOnce(map(OneStepLeft, LM));
F2:=LM->ListTools:-FlattenOnce(map(OneStepRight, LM));

T:=[A1];
for a in L1 do
T:=F1(T);
od;

for a in L2 do
T:=F2(T);
od;

R:=map(t->convert(t,Matrix), T);
if nops(R)=0 then return `no solutions` else R[] fi;

end proc:
>

Numbrix := proc( M :: ~Matrix, { inline :: truefalse := false } )

local S, adjacent, eq, i, initial, j, k, kk, m, n, one, single, sol, unique, val, var, x;

    (m,n) := upperbound(M);

    initial := &and(seq(seq(ifelse(M[i,j] = 0
                                   , NULL
                                   , x[i,j,M[i,j]]
                                  )
                            , i = 1..m)
                        , j = 1..n));

    adjacent := &and(seq(seq(seq(x[i,j,k] &implies &or(NULL
                                                       , ifelse(i>1, x[i-1, j, k+1], NULL)
                                                       , ifelse(i<m, x[i+1, j, k+1], NULL)
                                                       , ifelse(j>1, x[i, j-1, k+1], NULL)
                                                       , ifelse(j<n, x[i, j+1, k+1], NULL)
                                                      )
                                 , i = 1..m)
                             , j = 1..n)
                         , k = 1 .. m*n-1));

    one := &or(seq(seq(x[i,j,1], i=1..m), j=1..n));


    single := &not(&or(seq(seq(seq(seq(x[i,j,k] &and x[i,j,kk], kk = k+1..m*n), k = 1..m*n-1)
                                , i = 1..m), j = 1..n)));

    sol := Logic:-Satisfy(&and(initial, adjacent, one, single));

    if sol = NULL then
        error "no solution";
    end if;
if inline then
        S := M;
     else
        S := Matrix(m,n);
    end if;

    for eq in sol do
        (var, val) := op(eq);
        if val then
            S[op(1..2, var)] := op(3,var);
        end if;
    end do;
    S;
end proc:

           Two simple examples

>

A:=<0,0,5; 0,0,0; 0,0,9>;
# The unique solution
NumbrixPuzzle(A);

A:=<0,0,5; 0,0,0; 0,8,0>;
# 4 solutions
NumbrixPuzzle(A);

Matrix(3, 3, {(1, 1) = 0, (1, 2) = 0, (1, 3) = 5, (2, 1) = 0, (2, 2) = 0, (2, 3) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = 9})



Matrix(3, 3, {(1, 1) = 3, (1, 2) = 4, (1, 3) = 5, (2, 1) = 2, (2, 2) = 7, (2, 3) = 6, (3, 1) = 1, (3, 2) = 8, (3, 3) = 9})



Matrix(3, 3, {(1, 1) = 0, (1, 2) = 0, (1, 3) = 5, (2, 1) = 0, (2, 2) = 0, (2, 3) = 0, (3, 1) = 0, (3, 2) = 8, (3, 3) = 0})



Matrix(%id = 18446746210121682686), Matrix(%id = 18446746210121682806), Matrix(%id = 18446746210121674750), Matrix(%id = 18446746210121674870)

 (1)


Comparison with Numbrix procedure. The example is taken from
http://rosettacode.org/wiki/Solve_a_Numbrix_puzzle

>

 A:=<0, 0, 0, 0, 0, 0, 0, 0, 0;
 0, 0, 46, 45, 0, 55, 74, 0, 0;
 0, 38, 0, 0, 43, 0, 0, 78, 0;
 0, 35, 0, 0, 0, 0, 0, 71, 0;
 0, 0, 33, 0, 0, 0, 59, 0, 0;
 0, 17, 0, 0, 0, 0, 0, 67, 0;
 0, 18, 0, 0, 11, 0, 0, 64, 0;
 0, 0, 24, 21, 0, 1, 2, 0, 0;
 0, 0, 0, 0, 0, 0, 0, 0, 0>;
CodeTools:-Usage(NumbrixPuzzle(A));
CodeTools:-Usage(Numbrix(A));

Matrix(9, 9, {(1, 1) = 0, (1, 2) = 0, (1, 3) = 0, (1, 4) = 0, (1, 5) = 0, (1, 6) = 0, (1, 7) = 0, (1, 8) = 0, (1, 9) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 46, (2, 4) = 45, (2, 5) = 0, (2, 6) = 55, (2, 7) = 74, (2, 8) = 0, (2, 9) = 0, (3, 1) = 0, (3, 2) = 38, (3, 3) = 0, (3, 4) = 0, (3, 5) = 43, (3, 6) = 0, (3, 7) = 0, (3, 8) = 78, (3, 9) = 0, (4, 1) = 0, (4, 2) = 35, (4, 3) = 0, (4, 4) = 0, (4, 5) = 0, (4, 6) = 0, (4, 7) = 0, (4, 8) = 71, (4, 9) = 0, (5, 1) = 0, (5, 2) = 0, (5, 3) = 33, (5, 4) = 0, (5, 5) = 0, (5, 6) = 0, (5, 7) = 59, (5, 8) = 0, (5, 9) = 0, (6, 1) = 0, (6, 2) = 17, (6, 3) = 0, (6, 4) = 0, (6, 5) = 0, (6, 6) = 0, (6, 7) = 0, (6, 8) = 67, (6, 9) = 0, (7, 1) = 0, (7, 2) = 18, (7, 3) = 0, (7, 4) = 0, (7, 5) = 11, (7, 6) = 0, (7, 7) = 0, (7, 8) = 64, (7, 9) = 0, (8, 1) = 0, (8, 2) = 0, (8, 3) = 24, (8, 4) = 21, (8, 5) = 0, (8, 6) = 1, (8, 7) = 2, (8, 8) = 0, (8, 9) = 0, (9, 1) = 0, (9, 2) = 0, (9, 3) = 0, (9, 4) = 0, (9, 5) = 0, (9, 6) = 0, (9, 7) = 0, (9, 8) = 0, (9, 9) = 0})



memory used=7.85MiB, alloc change=-3.01MiB, cpu time=172.00ms, real time=212.00ms, gc time=93.75ms



Matrix(9, 9, {(1, 1) = 49, (1, 2) = 50, (1, 3) = 51, (1, 4) = 52, (1, 5) = 53, (1, 6) = 54, (1, 7) = 75, (1, 8) = 76, (1, 9) = 81, (2, 1) = 48, (2, 2) = 47, (2, 3) = 46, (2, 4) = 45, (2, 5) = 44, (2, 6) = 55, (2, 7) = 74, (2, 8) = 77, (2, 9) = 80, (3, 1) = 37, (3, 2) = 38, (3, 3) = 39, (3, 4) = 40, (3, 5) = 43, (3, 6) = 56, (3, 7) = 73, (3, 8) = 78, (3, 9) = 79, (4, 1) = 36, (4, 2) = 35, (4, 3) = 34, (4, 4) = 41, (4, 5) = 42, (4, 6) = 57, (4, 7) = 72, (4, 8) = 71, (4, 9) = 70, (5, 1) = 31, (5, 2) = 32, (5, 3) = 33, (5, 4) = 14, (5, 5) = 13, (5, 6) = 58, (5, 7) = 59, (5, 8) = 68, (5, 9) = 69, (6, 1) = 30, (6, 2) = 17, (6, 3) = 16, (6, 4) = 15, (6, 5) = 12, (6, 6) = 61, (6, 7) = 60, (6, 8) = 67, (6, 9) = 66, (7, 1) = 29, (7, 2) = 18, (7, 3) = 19, (7, 4) = 20, (7, 5) = 11, (7, 6) = 62, (7, 7) = 63, (7, 8) = 64, (7, 9) = 65, (8, 1) = 28, (8, 2) = 25, (8, 3) = 24, (8, 4) = 21, (8, 5) = 10, (8, 6) = 1, (8, 7) = 2, (8, 8) = 3, (8, 9) = 4, (9, 1) = 27, (9, 2) = 26, (9, 3) = 23, (9, 4) = 22, (9, 5) = 9, (9, 6) = 8, (9, 7) = 7, (9, 8) = 6, (9, 9) = 5})



memory used=1.21GiB, alloc change=307.02MiB, cpu time=37.00s, real time=31.88s, gc time=9.30s



Matrix(%id = 18446746210094669942)

 (2)


In the example below, which has 104 solutions, the  Numbrix  procedure is faster.

>

C:=Matrix(5,{(1,1)=1,(5,5)=25});
CodeTools:-Usage(NumbrixPuzzle(C)):
nops([%]);
CodeTools:-Usage(Numbrix(C)):

Matrix(5, 5, {(1, 1) = 1, (1, 2) = 0, (1, 3) = 0, (1, 4) = 0, (1, 5) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 0, (2, 4) = 0, (2, 5) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = 0, (3, 4) = 0, (3, 5) = 0, (4, 1) = 0, (4, 2) = 0, (4, 3) = 0, (4, 4) = 0, (4, 5) = 0, (5, 1) = 0, (5, 2) = 0, (5, 3) = 0, (5, 4) = 0, (5, 5) = 25})



memory used=0.94GiB, alloc change=-22.96MiB, cpu time=12.72s, real time=11.42s, gc time=2.28s



104



memory used=34.74MiB, alloc change=0 bytes, cpu time=781.00ms, real time=783.00ms, gc time=0ns


>






Download NumbrixPuzzle.mw

I Have a problem in Do loop...

Asked by: amrramadaneg 76
do-loop limit
July 28 2019
0  2

Dears, greeting for all

I have a problem, I try to explain it by a figure

This formula does not work.

I need to substitute n=0 to give G_n+1 as a function of the parameter s, then find the limit.

.where G_n is a function in s.

this is the result



Wrong values for Eigenvalues, depending on Digits ...

Asked by: Dobrica 20
linearalgebra datatype digits
July 27 2019
4  3

Hello!

I want to calculate Eigenvalues. Depending on values for digits and which datatype I choose Maple sometimes returns zero as Eigenvalues. Maybe there is a problem with the used routines: CLAPACK sw_dgeevx_, CLAPACK sw_zgeevx_.

Thank you for your suggestions!


``

>



Problems LinearAlgebra:-Eigenvalues, Digits, ':-datatype' = ':-sfloat', ':-datatype' = ':-complex'( ':-sfloat' )


>

restart;

>

interface( ':-displayprecision' = 5 ):

>

infolevel['LinearAlgebra'] := 5;
myPlatform := kernelopts( ':-platform' );
myVersion := kernelopts( ':-version' );

5



"windows"



`Maple 2018.2, X86 64 WINDOWS, Nov 16 2018, Build ID 1362973`

(1.1)

Example 1


>

A1 := Matrix( 5, 5, [[0, 1, 0, 0, 0], [0, 0, 1, 0, 0], [0, 0, 0, 1, 0], [0, 0, 0, 0, 1], [-10201/1000, 30199/10000, -5049/250, 97/50, -48/5]] );

Matrix(5, 5, {(1, 1) = 0, (1, 2) = 1, (1, 3) = 0, (1, 4) = 0, (1, 5) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 1, (2, 4) = 0, (2, 5) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = 0, (3, 4) = 1, (3, 5) = 0, (4, 1) = 0, (4, 2) = 0, (4, 3) = 0, (4, 4) = 0, (4, 5) = 1, (5, 1) = -10201/1000, (5, 2) = 30199/10000, (5, 3) = -5049/250, (5, 4) = 97/50, (5, 5) = -48/5})

(1.1.1)
>

LinearAlgebra:-Eigenvalues( A1 );

CharacteristicPolynomial: working on determinant of minor 2
CharacteristicPolynomial: working on determinant of minor 3
CharacteristicPolynomial: working on determinant of minor 4
CharacteristicPolynomial: working on determinant of minor 5



Vector(5, {(1) = -10, (2) = 1/10+I, (3) = 1/10-I, (4) = 1/10+I, (5) = 1/10-I})

(1.1.2)
>

A11 := Matrix( op( 1, A1 ),( i,j ) -> evalf( A1[i,j] ), ':-datatype' = ':-sfloat' );

Matrix(5, 5, {(1, 1) = 0., (1, 2) = 1.00000, (1, 3) = 0., (1, 4) = 0., (1, 5) = 0., (2, 1) = 0., (2, 2) = 0., (2, 3) = 1.00000, (2, 4) = 0., (2, 5) = 0., (3, 1) = 0., (3, 2) = 0., (3, 3) = 0., (3, 4) = 1.00000, (3, 5) = 0., (4, 1) = 0., (4, 2) = 0., (4, 3) = 0., (4, 4) = 0., (4, 5) = 1.00000, (5, 1) = -10.20100, (5, 2) = 3.01990, (5, 3) = -20.19600, (5, 4) = 1.94000, (5, 5) = -9.60000})

(1.1.3)
>

Digits := 89;
LinearAlgebra:-Eigenvalues( A11 );

Digits := 89



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881249354686)

(1.1.4)
>

Digits := 90;
LinearAlgebra:-Eigenvalues( A11 );

Digits := 90



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881249352150)

(1.1.5)
>

A12 := Matrix( op( 1, A1 ),( i,j ) -> evalf( A1[i,j] ), ':-datatype' = ':-complex'( ':-sfloat' ) );

Matrix(5, 5, {(1, 1) = 0.+0.*I, (1, 2) = 1.00000+0.*I, (1, 3) = 0.+0.*I, (1, 4) = 0.+0.*I, (1, 5) = 0.+0.*I, (2, 1) = 0.+0.*I, (2, 2) = 0.+0.*I, (2, 3) = 1.00000+0.*I, (2, 4) = 0.+0.*I, (2, 5) = 0.+0.*I, (3, 1) = 0.+0.*I, (3, 2) = 0.+0.*I, (3, 3) = 0.+0.*I, (3, 4) = 1.00000+0.*I, (3, 5) = 0.+0.*I, (4, 1) = 0.+0.*I, (4, 2) = 0.+0.*I, (4, 3) = 0.+0.*I, (4, 4) = 0.+0.*I, (4, 5) = 1.00000+0.*I, (5, 1) = -10.20100+0.*I, (5, 2) = 3.01990+0.*I, (5, 3) = -20.19600+0.*I, (5, 4) = 1.94000+0.*I, (5, 5) = -9.60000+0.*I})

(1.1.6)
>

Digits := 100;
LinearAlgebra:-Eigenvalues( A12 );

Digits := 100



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881249345038)

(1.1.7)
>

Digits := 250;
LinearAlgebra:-Eigenvalues( A12 );

Digits := 250



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881342643606)

(1.1.8)
>



>



Example 2


>

A2 := Matrix(3, 3, [[0, 1, 0], [0, 0, 1], [3375, -675, 45]]);

Matrix(3, 3, {(1, 1) = 0, (1, 2) = 1, (1, 3) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 1, (3, 1) = 3375, (3, 2) = -675, (3, 3) = 45})

(1.2.1)
>

LinearAlgebra:-Eigenvalues( A2 );

IntegerCharacteristicPolynomial: Computing characteristic polynomial for a 3 x 3 matrix

IntegerCharacteristicPolynomial: Using prime 33554393
IntegerCharacteristicPolynomial: Using prime 33554383
IntegerCharacteristicPolynomial: Used total of  2  prime(s)



Vector(3, {(1) = 15, (2) = 15, (3) = 15})

(1.2.2)
>

A21 := Matrix( op( 1, A2 ),( i,j ) -> evalf( A2[i,j] ), ':-datatype' = ':-sfloat' );

Matrix(3, 3, {(1, 1) = 0., (1, 2) = 1.00000, (1, 3) = 0., (2, 1) = 0., (2, 2) = 0., (2, 3) = 1.00000, (3, 1) = 3375.00000, (3, 2) = -675.00000, (3, 3) = 45.00000})

(1.2.3)
>

Digits := 77;
LinearAlgebra:-Eigenvalues( A21 );

Digits := 77



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881342621686)

(1.2.4)
>

Digits := 78;
LinearAlgebra:-Eigenvalues( A21 );

Digits := 78



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881342617230)

(1.2.5)
>

A22 := Matrix( op( 1, A2 ),( i,j ) -> evalf( A2[i,j] ), ':-datatype' = ':-complex'( ':-sfloat' ) );

Matrix(3, 3, {(1, 1) = 0.+0.*I, (1, 2) = 1.00000+0.*I, (1, 3) = 0.+0.*I, (2, 1) = 0.+0.*I, (2, 2) = 0.+0.*I, (2, 3) = 1.00000+0.*I, (3, 1) = 3375.00000+0.*I, (3, 2) = -675.00000+0.*I, (3, 3) = 45.00000+0.*I})

(1.2.6)
>

Digits := 58;
LinearAlgebra:-Eigenvalues( A22 );

Digits := 58



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881342614934)

(1.2.7)
>

Digits := 59;
LinearAlgebra:-Eigenvalues( A22 );

Digits := 59



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881325525942)

(1.2.8)
>



>



Example 3


>

A3 := Matrix(4, 4, [[0, 1, 0, 0], [0, 0, 1, 0], [0, 0, 0, 1], [-48841, 8840, -842, 40]]);

Matrix(4, 4, {(1, 1) = 0, (1, 2) = 1, (1, 3) = 0, (1, 4) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 1, (2, 4) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = 0, (3, 4) = 1, (4, 1) = -48841, (4, 2) = 8840, (4, 3) = -842, (4, 4) = 40})

(1.3.1)
>

LinearAlgebra:-Eigenvalues( A3 );

IntegerCharacteristicPolynomial: Computing characteristic polynomial for a 4 x 4 matrix
IntegerCharacteristicPolynomial: Using prime 33554393

IntegerCharacteristicPolynomial: Using prime 33554383
IntegerCharacteristicPolynomial: Used total of  2  prime(s)



Vector(4, {(1) = 10+11*I, (2) = 10-11*I, (3) = 10+11*I, (4) = 10-11*I})

(1.3.2)
>

A31 := Matrix( op( 1, A3 ),( i,j ) -> evalf( A3[i,j] ), ':-datatype' = ':-sfloat' );

Matrix(4, 4, {(1, 1) = 0., (1, 2) = 1.00000, (1, 3) = 0., (1, 4) = 0., (2, 1) = 0., (2, 2) = 0., (2, 3) = 1.00000, (2, 4) = 0., (3, 1) = 0., (3, 2) = 0., (3, 3) = 0., (3, 4) = 1.00000, (4, 1) = -48841.00000, (4, 2) = 8840.00000, (4, 3) = -842.00000, (4, 4) = 40.00000})

(1.3.3)
>

Digits := 75;
LinearAlgebra:-Eigenvalues( A31 );

Digits := 75



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881324662046)

(1.3.4)
>

Digits := 76;
LinearAlgebra:-Eigenvalues( A31 );

Digits := 76



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881324657710)

(1.3.5)
>

A32 := Matrix( op( 1, A3 ),( i,j ) -> evalf( A3[i,j] ), ':-datatype' = ':-complex'( ':-sfloat' ) );

Matrix(4, 4, {(1, 1) = 0.+0.*I, (1, 2) = 1.00000+0.*I, (1, 3) = 0.+0.*I, (1, 4) = 0.+0.*I, (2, 1) = 0.+0.*I, (2, 2) = 0.+0.*I, (2, 3) = 1.00000+0.*I, (2, 4) = 0.+0.*I, (3, 1) = 0.+0.*I, (3, 2) = 0.+0.*I, (3, 3) = 0.+0.*I, (3, 4) = 1.00000+0.*I, (4, 1) = -48841.00000+0.*I, (4, 2) = 8840.00000+0.*I, (4, 3) = -842.00000+0.*I, (4, 4) = 40.00000+0.*I})

(1.3.6)
>

Digits := 100;
LinearAlgebra:-Eigenvalues( A32 );

Digits := 100



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881324648198)

(1.3.7)
>

Digits := 250;
LinearAlgebra:-Eigenvalues( A32 );

Digits := 250



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881327288182)

(1.3.8)
>



>



Example 4


>

A4 := Matrix(8, 8, [[0, 1, 0, 0, 0, 0, 0, 0], [0, 0, 1, 0, 0, 0, 0, 0], [0, 0, 0, 1, 0, 0, 0, 0], [0, 0, 0, 0, 1, 0, 0, 0], [0, 0, 0, 0, 0, 1, 0, 0], [0, 0, 0, 0, 0, 0, 1, 0], [0, 0, 0, 0, 0, 0, 0, 1], [-1050625/20736, 529925/1296, -15417673/10368, 3622249/1296, -55468465/20736, 93265/108, -1345/8, 52/3]]);

Matrix(8, 8, {(1, 1) = 0, (1, 2) = 1, (1, 3) = 0, (1, 4) = 0, (1, 5) = 0, (1, 6) = 0, (1, 7) = 0, (1, 8) = 0, (2, 1) = 0, (2, 2) = 0, (2, 3) = 1, (2, 4) = 0, (2, 5) = 0, (2, 6) = 0, (2, 7) = 0, (2, 8) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = 0, (3, 4) = 1, (3, 5) = 0, (3, 6) = 0, (3, 7) = 0, (3, 8) = 0, (4, 1) = 0, (4, 2) = 0, (4, 3) = 0, (4, 4) = 0, (4, 5) = 1, (4, 6) = 0, (4, 7) = 0, (4, 8) = 0, (5, 1) = 0, (5, 2) = 0, (5, 3) = 0, (5, 4) = 0, (5, 5) = 0, (5, 6) = 1, (5, 7) = 0, (5, 8) = 0, (6, 1) = 0, (6, 2) = 0, (6, 3) = 0, (6, 4) = 0, (6, 5) = 0, (6, 6) = 0, (6, 7) = 1, (6, 8) = 0, (7, 1) = 0, (7, 2) = 0, (7, 3) = 0, (7, 4) = 0, (7, 5) = 0, (7, 6) = 0, (7, 7) = 0, (7, 8) = 1, (8, 1) = -1050625/20736, (8, 2) = 529925/1296, (8, 3) = -15417673/10368, (8, 4) = 3622249/1296, (8, 5) = -55468465/20736, (8, 6) = 93265/108, (8, 7) = -1345/8, (8, 8) = 52/3})

(1.4.1)
>

LinearAlgebra:-Eigenvalues( A4 );

CharacteristicPolynomial: working on determinant of minor 2
CharacteristicPolynomial: working on determinant of minor 3

CharacteristicPolynomial: working on determinant of minor 4
CharacteristicPolynomial: working on determinant of minor 5
CharacteristicPolynomial: working on determinant of minor 6
CharacteristicPolynomial: working on determinant of minor 7
CharacteristicPolynomial: working on determinant of minor 8



Vector(8, {(1) = 1/3-(1/4)*I, (2) = 1/3+(1/4)*I, (3) = 4-5*I, (4) = 4+5*I, (5) = 1/3-(1/4)*I, (6) = 1/3+(1/4)*I, (7) = 4-5*I, (8) = 4+5*I})

(1.4.2)
>

A41 := Matrix( op( 1, A4 ),( i,j ) -> evalf( A4[i,j] ), ':-datatype' = ':-sfloat' );

Matrix(8, 8, {(1, 1) = 0., (1, 2) = 1.00000, (1, 3) = 0., (1, 4) = 0., (1, 5) = 0., (1, 6) = 0., (1, 7) = 0., (1, 8) = 0., (2, 1) = 0., (2, 2) = 0., (2, 3) = 1.00000, (2, 4) = 0., (2, 5) = 0., (2, 6) = 0., (2, 7) = 0., (2, 8) = 0., (3, 1) = 0., (3, 2) = 0., (3, 3) = 0., (3, 4) = 1.00000, (3, 5) = 0., (3, 6) = 0., (3, 7) = 0., (3, 8) = 0., (4, 1) = 0., (4, 2) = 0., (4, 3) = 0., (4, 4) = 0., (4, 5) = 1.00000, (4, 6) = 0., (4, 7) = 0., (4, 8) = 0., (5, 1) = 0., (5, 2) = 0., (5, 3) = 0., (5, 4) = 0., (5, 5) = 0., (5, 6) = 1.00000, (5, 7) = 0., (5, 8) = 0., (6, 1) = 0., (6, 2) = 0., (6, 3) = 0., (6, 4) = 0., (6, 5) = 0., (6, 6) = 0., (6, 7) = 1.00000, (6, 8) = 0., (7, 1) = 0., (7, 2) = 0., (7, 3) = 0., (7, 4) = 0., (7, 5) = 0., (7, 6) = 0., (7, 7) = 0., (7, 8) = 1.00000, (8, 1) = -50.66671, (8, 2) = 408.89275, (8, 3) = -1487.04408, (8, 4) = 2794.94522, (8, 5) = -2674.98384, (8, 6) = 863.56481, (8, 7) = -168.12500, (8, 8) = 17.33333})

 (1.4.3)
>

Digits := 74;
LinearAlgebra:-Eigenvalues( A41 );

Digits := 74



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881317242630)

(1.4.4)
>

Digits := 75;
LinearAlgebra:-Eigenvalues( A41 );

Digits := 75



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_dgeevx_



Vector[column](%id = 18446745881317239134)

(1.4.5)
>

A42 := Matrix( op( 1, A4 ),( i,j ) -> evalf( A4[i,j] ), ':-datatype' = ':-complex'( ':-sfloat' ) );

Matrix(8, 8, {(1, 1) = 0.+0.*I, (1, 2) = 1.00000+0.*I, (1, 3) = 0.+0.*I, (1, 4) = 0.+0.*I, (1, 5) = 0.+0.*I, (1, 6) = 0.+0.*I, (1, 7) = 0.+0.*I, (1, 8) = 0.+0.*I, (2, 1) = 0.+0.*I, (2, 2) = 0.+0.*I, (2, 3) = 1.00000+0.*I, (2, 4) = 0.+0.*I, (2, 5) = 0.+0.*I, (2, 6) = 0.+0.*I, (2, 7) = 0.+0.*I, (2, 8) = 0.+0.*I, (3, 1) = 0.+0.*I, (3, 2) = 0.+0.*I, (3, 3) = 0.+0.*I, (3, 4) = 1.00000+0.*I, (3, 5) = 0.+0.*I, (3, 6) = 0.+0.*I, (3, 7) = 0.+0.*I, (3, 8) = 0.+0.*I, (4, 1) = 0.+0.*I, (4, 2) = 0.+0.*I, (4, 3) = 0.+0.*I, (4, 4) = 0.+0.*I, (4, 5) = 1.00000+0.*I, (4, 6) = 0.+0.*I, (4, 7) = 0.+0.*I, (4, 8) = 0.+0.*I, (5, 1) = 0.+0.*I, (5, 2) = 0.+0.*I, (5, 3) = 0.+0.*I, (5, 4) = 0.+0.*I, (5, 5) = 0.+0.*I, (5, 6) = 1.00000+0.*I, (5, 7) = 0.+0.*I, (5, 8) = 0.+0.*I, (6, 1) = 0.+0.*I, (6, 2) = 0.+0.*I, (6, 3) = 0.+0.*I, (6, 4) = 0.+0.*I, (6, 5) = 0.+0.*I, (6, 6) = 0.+0.*I, (6, 7) = 1.00000+0.*I, (6, 8) = 0.+0.*I, (7, 1) = 0.+0.*I, (7, 2) = 0.+0.*I, (7, 3) = 0.+0.*I, (7, 4) = 0.+0.*I, (7, 5) = 0.+0.*I, (7, 6) = 0.+0.*I, (7, 7) = 0.+0.*I, (7, 8) = 1.00000+0.*I, (8, 1) = -50.66671+0.*I, (8, 2) = 408.89275+0.*I, (8, 3) = -1487.04408+0.*I, (8, 4) = 2794.94522+0.*I, (8, 5) = -2674.98384+0.*I, (8, 6) = 863.56481+0.*I, (8, 7) = -168.12500+0.*I, (8, 8) = 17.33333+0.*I})

 (1.4.6)
>

Digits := 100;
LinearAlgebra:-Eigenvalues( A42 );

Digits := 100



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881317227806)

(1.4.7)
>

Digits := 250;
LinearAlgebra:-Eigenvalues( A42 );

Digits := 250



Eigenvalues: calling external function
Eigenvalues: initializing the output object
Eigenvalues: using software external library
Eigenvalues: CLAPACK sw_zgeevx_



Vector[column](%id = 18446745881356880102)

(1.4.8)
>



>



>



>



>



>



>



>



>



>



``




Download Problems_LinearAlgebra_Eigenvalues.mw

i want to plot a few equation with animate plot or...

Asked by: kambiz1199 170
animate plotting
July 27 2019
1  7

hi

i want to plot this equations , i want to show that step by step and remind previous . i plot with animte plot but it do not show the previous



restart;
with(plottools);
co := blue;
with(plots);

t := 1;
for i from 20 by -1 to 0 do t := t+1; a[i] := -i*x/t+i; p[i] := plot(a[i], x = 0 .. 20, y = 0 .. 20, color = co, thickness = 3) end do;

plots[animate](plot, [a[k], x = 0 .. 20, y = 0 .. 20], k = [seq(i, i = 1 .. 20)]);

How to get the result of this limit?...

Asked by: minhthien2016 415
sum
July 27 2019
1  2

How to get the result of this limit? I don't get the result.


limit(sum(1/(i*sqrt(i+1)+(i+1)*sqrt(i)), i = 1 .. n), n = infinity);

With Mathematica, I got the output is 1.

Fourier transform ...

Asked by: arshl 15
fourier-transform duplicate-question
July 24 2019
1  10

Hi. I want to get a Fourier transform under the equation How to do this? Equation_is.docx

Bugs with RealDomain:-solve ?...

Asked by: minhthien2016 415
solve realdomain
July 22 2019
1  5

I want to solve the equation (-2*cos(x)^2+2*sin(x+(1/4)*Pi)^2-1)/sqrt(-x^2+4*x) = 0 in RealDomain. I tried


restart;
RealDomain:-solve({(-2*cos(x)^2+2*sin(x+(1/4)*Pi)^2-1)/sqrt(-x^2+4*x) = 0}, {x});

I got four solutions

If I work around

restart;
 RealDomain:-solve({-x^2+4*x > 0, (-2*cos(x)^2+2*sin(x+(1/4)*Pi)^2-1)/sqrt(-x^2+4*x) = 0}, x);

I only got two solutions

With Mathematica, I got three solutions

That is mean, Maple lost the solution x = 5*Pi/4. I check this thing

f:= x-> (-2*cos(x)^2+2*sin(x+(1/4)*Pi)^2-1)/sqrt(4*x-x^2) ;
f(5*Pi/4);

and got the result 0.

Are these bugs?

Homotopy Perturbation method...

Asked by: Bernard Afful 20
homework pde pdsolve
July 21 2019
1  6

I'm currently working my thesis and can someone help me to write a code to solve this IVP

u_t + 2×u²×u_x−(u_x)²−½×u_{xx}×u=0

with initial condition

u(x,0)=-tanh(x)



How can I solve this trigonometric equation?...

Asked by: minhthien2016 415
solve trigonometry explicit
July 21 2019
2  13

The equation sin(9*x-(1/3)*Pi) = sin(7*x-(1/3)*Pi) can be solved easy by hand with solutions k*Pi and -Pi/48 + K*Pi/8. With Maple, I tried
solve({sin(9*x-(1/3)*Pi) = sin(7*x-(1/3)*Pi)}, x, explicit, allsolutions)

I don't get the above solutions. How can I get these solutions?

Visualising solutions to sums of polynomials...

Asked by: Annonymouse 160
polynomial plotting
July 19 2019
0  2

I'm working towards creating a way to visualise real polynomial ideals! (or at least the solutions of the polynomials in the ideals) this code creates a plot showing the solutions to all the polynomials in the ideal generated by P1 and P2 (these are specified in the code)

with(plots);
P1 := x^2+2*y^2-3;
solve(P1, y);
Plot1 := plot([%], x = -2 .. 2);

P2 := -2*x^2+2*x*y+3*y^2+x-4;
solve(%, y);
Plot2 := plot([%], x = -4 .. 2);

P2*a+P1;
solve(%, y);
seq(plot([%], x = -4 .. 2), a = 0 .. 10, .1);
display(%, Plot1, Plot2)




This is because when you multiply two polynomials their set of solution curves is just the union of the sets of curves associated with the previous polynomials.

For the next step I'd like to create a graph of the solutions associated with an ideal with three generators. To stop this from being excessively messy I'd like to do it with the RGB value of the colour of a curve is determined by  a and b where the formula for a generic polynomial that we are solving and graphing is given by:

P1+a*P2+b*P3;

where P3 is given by

P3 := x*y-3

I've tried various ways to use cury to make this work (my intuition is cury is the right function to use here)  but got no where. Any ideas how to procede?

pdsolve 2D equations with unknown parameter...

Asked by: fatemeh1090 65
parameter pde pdsolve
July 17 2019
0  0

possible to solve following equation with unknown parameter omega.

parameter constant.

I see before for one dimension ode this type equation was solved.

Now for 2d equation is possible?

can consider or I can send again.

Best

2d-2



worksheet mode and evaluating ...

Asked by: fatemeh1090 65
2dmath worksheet editing
July 14 2019
0  1

In worksheet mode when me is writing my code, running code, evaluating is and can not work well with maple?

How can inactive  action? Because have to wait many times and is very boring for me.



Study of a conic without "geometry"...

Asked by: JAMET 425
linearalgebra ellipse
July 12 2019
1  3
How to study this ellipse with LinearAlgebra without "geometry" eq := -185173378616457/6178315520000*x+86813215770519/24713262080000*(y^2)+126906272070543/24713262080000*(x^2)+256107247454961/6178315520000+(2514994832007/950510080000*x)*y-9123740375967/6178315520000*y = 0 Axis ? foci ? ...Thank you
First 24 25 26 27 28 29 30 Last Page 26 of 63
