By the way, next Wednesday & Thursday, Nov 2-3, is the Maple Conference 2022, hosted by Maplesoft.

The conference program shows a talk on the Thursday titled, "Maple Programming: An Overview on Creating Packages", Paul DeMarco, Senior Director, Maple Development.

@Ronan Put the code with the $include directives in a plaintext .mpl file. Then use the read command on that single file.

ps. It seems weirdly and unnecessarily roundabout to write the procedure such as your SignedArea in a Maple worksheet, then use commands in the worksheet that store/export it as a .mpl file. I'd rather write my source in plaintext files to begin with, so that I could use decent revision control, a code editor of my choice, etc. I could read them into any session as I wanted, while prototyping functionality. Once satisfied I could write a module (again: itself authored in a plaintext file, with $include directives for its member procedures) and either read that in or store it all in a .mla archive. It seems to me that you are having difficulty in letting go of the habit of having your long-term build methodology use the GUI for lower level steps.

The proposed idea is to have a long-term build methodology that is purely textfile based. In the end it could all be loaded (and optionally stored to .mla) by calling read on one master build .mpl plaintext file. That single read call could be made in the GUI, or from a shell (running command line interface of Maple, interactively or as a batch/script execution which I suspect is what Joe meant elsewhere as you cited).

Sorry, I don't have time just now to write in more detail, or to reconfigure your whole example.

@tomleslie I really like the way your procedure F accepts just a single parameter (which will become the animating parameter when F gets used in the animate call.) I vote up.

I think that's an important improvement because it makes the later animate call much simpler. Thus the programming difficulties (for those less proficient than you) are split more usefully. Producing any single frame is one programming subtask. And the animating subtask (which can challenge beginners, say) is now more straightforward.

@romanrieme

Perhaps you could have each frame contain a plotted circle (with some coloring or pattern), or a polygonal shape. Then you could have construction of that frame rotate that accordingly.

I suggest creating a procedure that will accept the two position values along with a rotation value, and construct the plot of a desired shape with its rotation visually apparent. In other words, that procedure would accept some three values and return a plot, which could be a frame of your animation. Then you could call animate on that procedure.

Did you somehow expect the pointplot command to know that the data you're passing it come from a system of differential equations in which the computed functions happen to represent a rotating ball? Otherwise I don't see how having a third component in the list for the pointplot command would be a natural way to specify the quite esoteric property of some rotation of the symbol.

@brian bovril Ok, so now we have the key detail that you want to copy&paste directly from the Maple interface. Before I suggested ExportMatrix in case you wanted to export to a file.

So here's a way, using printf, to produce plaintext output in the Maple interface that can be directly copy&pasted.

I had alluded to that in my Answer, but now that I know that's the effect that you're after I'll give it explicitly.

restart:
with(combinat):with(StringTools,DeleteSpace):
abil:=[1407,1408,1409,1411]:
DBL:=choose(abil,2):
score:=[2,0]:
ans:=seq([DBL[j][],score[1],DBL[numelems(DBL)-j+1][],score[2]],
         j=1..numelems(DBL)/2),
     seq([DBL[numelems(DBL)-j+1][],score[1],DBL[j][],score[2]],
         j=1..numelems(DBL)/2):

seq(printf("%s\n",
           DeleteSpace(sprintf("%a",
                               ans[i]))[2..-2]),
    i=1..nops([ans]));

1407,1408,2,1409,1411,0
1407,1409,2,1408,1411,0
1407,1411,2,1408,1409,0
1409,1411,2,1407,1408,0
1408,1411,2,1407,1409,0
1408,1409,2,1407,1411,0

There are other printf incantations which could get the same kind of result.

Which version of Maple?

Which version of Linux? Which JRE?

You might try changing the JRE.

I changed your Post into a Question.

Please try to be careful about submitting your queries as Question threads.

Are you using the stock Physics package that comes with your Maple version, or an update from the Maple cloud?

@Joe Riel I agree very much with the approach of using external text files (Maple source). I prefer having separate files for each part (eg. procedures, submodules, etc), using Maple's $include directive within the text source for the body of the module.

One of the important reasons for my preferring text source files is that common version control tools can be used.

@mmcdara Thanks, maybe you'll come across it later.

I don't really understand the purpose or advantage of defining the procedures P1,P2,P3 outside of the module body. Perhaps there is more going on in your actual examples.

I changed your Post into a Question.

A := exp(I*x):
simplify(conjugate(A),power) assuming x::real;

              exp(-I x)

@Carl Love It seems likely that \134n is intended there as the octal (ASCII) escape sequence in which \134 encodes backslash and \134n encodes \n (eventually interpreted as new line).

@ianmccr First, the Help page I cited earlier is about using 2D Input (and not any Typesetting package or extra facilities.) It's stock stuff, and probably ought to be perused by anyone using Maple's 2D Input mode.

Second, I don't know what your rfloor and lfloor commands are supposed to do. Do you know that you can use the special name `&lfoor;` as an infix operator? Do you know that it will pretty-print? (With a bit of work it could be made to render in upright Roman instead of italics when used thusly, I suspect.)

You seem to now be asking about something very different from your original query in this thread. If you have some scenario involving using that symbol (as input, or to get it as desired output) in a pretty-printed way then you could ask that in a separate Question.

@tomleslie [edited] After taking a second look (thanks) I don't know how he managed to get that result of 4. (Perhaps that was the result of some accidental editing of the code after execution...) His issue seems resolved now.
