I am a retired professor of chemistry at the University of Victoria, BC, Canada. My research areas are electrochemistry and surface science. I have been a user of Maple since about 1990.

MaplePrimes Activity


These are answers submitted by dharr

The help for CayleyTableGroup specifies: The single required argument is the Cayley table (or multiplication table): an n by n
 Matrix or Array, m, describing the group with n elements, where the [i, j] entry contains the positive integer k such that the product of the ith and j h group elements is the kth group element.

So this needs to be a matrix of integers.




restart;interface(rtablesize=12);

10

with(GroupTheory):

ct := <<e | p | q | r | s | t | u | v | w | x | y | z>, <p | q | e | y | u | w | z | r | x | t | v | s>, <q | e | p | v | z | x | s | y | t | w | r | u>, <r | z | t | s | e | y | v | x | p | u | q | w>, <s | w | y | e | r | q | x | u | z | v | t | p>, <t | r | z | x | w | u | e | q | y | p | s | v>, <u | x | v | p | y | e | t | z | s | r | w | q>, <v | u | x | z | q | r | y | w | e | s | p | t>, <w | y | s | t | x | z | p | e | v | q | u | r>, <x | v | u | w | t | s | q | p | r | e | z | y>, <y | s | w | u | p | v | r | t | q | z | e | x>, <z | t | r | q | v | p | w | s | u | y | x | e>>;

ct := Matrix(12, 12, {(1, 1) = e, (1, 2) = p, (1, 3) = q, (1, 4) = r, (1, 5) = s, (1, 6) = t, (1, 7) = u, (1, 8) = v, (1, 9) = w, (1, 10) = x, (1, 11) = y, (1, 12) = z, (2, 1) = p, (2, 2) = q, (2, 3) = e, (2, 4) = y, (2, 5) = u, (2, 6) = w, (2, 7) = z, (2, 8) = r, (2, 9) = x, (2, 10) = t, (2, 11) = v, (2, 12) = s, (3, 1) = q, (3, 2) = e, (3, 3) = p, (3, 4) = v, (3, 5) = z, (3, 6) = x, (3, 7) = s, (3, 8) = y, (3, 9) = t, (3, 10) = w, (3, 11) = r, (3, 12) = u, (4, 1) = r, (4, 2) = z, (4, 3) = t, (4, 4) = s, (4, 5) = e, (4, 6) = y, (4, 7) = v, (4, 8) = x, (4, 9) = p, (4, 10) = u, (4, 11) = q, (4, 12) = w, (5, 1) = s, (5, 2) = w, (5, 3) = y, (5, 4) = e, (5, 5) = r, (5, 6) = q, (5, 7) = x, (5, 8) = u, (5, 9) = z, (5, 10) = v, (5, 11) = t, (5, 12) = p, (6, 1) = t, (6, 2) = r, (6, 3) = z, (6, 4) = x, (6, 5) = w, (6, 6) = u, (6, 7) = e, (6, 8) = q, (6, 9) = y, (6, 10) = p, (6, 11) = s, (6, 12) = v, (7, 1) = u, (7, 2) = x, (7, 3) = v, (7, 4) = p, (7, 5) = y, (7, 6) = e, (7, 7) = t, (7, 8) = z, (7, 9) = s, (7, 10) = r, (7, 11) = w, (7, 12) = q, (8, 1) = v, (8, 2) = u, (8, 3) = x, (8, 4) = z, (8, 5) = q, (8, 6) = r, (8, 7) = y, (8, 8) = w, (8, 9) = e, (8, 10) = s, (8, 11) = p, (8, 12) = t, (9, 1) = w, (9, 2) = y, (9, 3) = s, (9, 4) = t, (9, 5) = x, (9, 6) = z, (9, 7) = p, (9, 8) = e, (9, 9) = v, (9, 10) = q, (9, 11) = u, (9, 12) = r, (10, 1) = x, (10, 2) = v, (10, 3) = u, (10, 4) = w, (10, 5) = t, (10, 6) = s, (10, 7) = q, (10, 8) = p, (10, 9) = r, (10, 10) = e, (10, 11) = z, (10, 12) = y, (11, 1) = y, (11, 2) = s, (11, 3) = w, (11, 4) = u, (11, 5) = p, (11, 6) = v, (11, 7) = r, (11, 8) = t, (11, 9) = q, (11, 10) = z, (11, 11) = e, (11, 12) = x, (12, 1) = z, (12, 2) = t, (12, 3) = r, (12, 4) = q, (12, 5) = v, (12, 6) = p, (12, 7) = w, (12, 8) = s, (12, 9) = u, (12, 10) = y, (12, 11) = x, (12, 12) = e})

elems:=convert(ct[1],list);
for i to nops(elems) do f(elems[i]):=i end do: #use remember table

[e, p, q, r, s, t, u, v, w, x, y, z]

M:=map(f,ct);

M := Matrix(12, 12, {(1, 1) = 1, (1, 2) = 2, (1, 3) = 3, (1, 4) = 4, (1, 5) = 5, (1, 6) = 6, (1, 7) = 7, (1, 8) = 8, (1, 9) = 9, (1, 10) = 10, (1, 11) = 11, (1, 12) = 12, (2, 1) = 2, (2, 2) = 3, (2, 3) = 1, (2, 4) = 11, (2, 5) = 7, (2, 6) = 9, (2, 7) = 12, (2, 8) = 4, (2, 9) = 10, (2, 10) = 6, (2, 11) = 8, (2, 12) = 5, (3, 1) = 3, (3, 2) = 1, (3, 3) = 2, (3, 4) = 8, (3, 5) = 12, (3, 6) = 10, (3, 7) = 5, (3, 8) = 11, (3, 9) = 6, (3, 10) = 9, (3, 11) = 4, (3, 12) = 7, (4, 1) = 4, (4, 2) = 12, (4, 3) = 6, (4, 4) = 5, (4, 5) = 1, (4, 6) = 11, (4, 7) = 8, (4, 8) = 10, (4, 9) = 2, (4, 10) = 7, (4, 11) = 3, (4, 12) = 9, (5, 1) = 5, (5, 2) = 9, (5, 3) = 11, (5, 4) = 1, (5, 5) = 4, (5, 6) = 3, (5, 7) = 10, (5, 8) = 7, (5, 9) = 12, (5, 10) = 8, (5, 11) = 6, (5, 12) = 2, (6, 1) = 6, (6, 2) = 4, (6, 3) = 12, (6, 4) = 10, (6, 5) = 9, (6, 6) = 7, (6, 7) = 1, (6, 8) = 3, (6, 9) = 11, (6, 10) = 2, (6, 11) = 5, (6, 12) = 8, (7, 1) = 7, (7, 2) = 10, (7, 3) = 8, (7, 4) = 2, (7, 5) = 11, (7, 6) = 1, (7, 7) = 6, (7, 8) = 12, (7, 9) = 5, (7, 10) = 4, (7, 11) = 9, (7, 12) = 3, (8, 1) = 8, (8, 2) = 7, (8, 3) = 10, (8, 4) = 12, (8, 5) = 3, (8, 6) = 4, (8, 7) = 11, (8, 8) = 9, (8, 9) = 1, (8, 10) = 5, (8, 11) = 2, (8, 12) = 6, (9, 1) = 9, (9, 2) = 11, (9, 3) = 5, (9, 4) = 6, (9, 5) = 10, (9, 6) = 12, (9, 7) = 2, (9, 8) = 1, (9, 9) = 8, (9, 10) = 3, (9, 11) = 7, (9, 12) = 4, (10, 1) = 10, (10, 2) = 8, (10, 3) = 7, (10, 4) = 9, (10, 5) = 6, (10, 6) = 5, (10, 7) = 3, (10, 8) = 2, (10, 9) = 4, (10, 10) = 1, (10, 11) = 12, (10, 12) = 11, (11, 1) = 11, (11, 2) = 5, (11, 3) = 9, (11, 4) = 7, (11, 5) = 2, (11, 6) = 8, (11, 7) = 4, (11, 8) = 6, (11, 9) = 3, (11, 10) = 12, (11, 11) = 1, (11, 12) = 10, (12, 1) = 12, (12, 2) = 6, (12, 3) = 4, (12, 4) = 3, (12, 5) = 8, (12, 6) = 2, (12, 7) = 9, (12, 8) = 5, (12, 9) = 7, (12, 10) = 11, (12, 11) = 10, (12, 12) = 1})

G := Group(M,labels=elems);

_m231969395104






Download Cayley.mw

I don't get an error message for the plot in Maple 2015, just an empty plot. But eval(S,w=1) gives -1.853089027*10^329399 so your numbers seem to be unreasonably large.




restart;

A:=(x^3-13*x^2+55*x-73)/(x-1)=0:
p:=numer(lhs(A));
realroot(p)[];

x^3-13*x^2+55*x-73

[169/64, 339/128]




Download realroot.mw

[Edited based on Carl's comment]. At least for real parameters (where the Matrix is Hermitian), there must be four eigenvectors.Not setting phi=Pi circumvents the OPs error message, and 4 eigenvectors are found, but then substituting phi=Pi leads to an error.




restart;

with(LinearAlgebra):

assume(k1,real,k2,real,m1,real,m2,real,phi,real);

Leave phi unspecified for now

A := <
          <0, 0, exp(I*k1) + m1, exp(I*k2) + m2>|
          <0, 0, exp(I*phi)*(exp(-I*k2) + m2), exp(-I*k1) + m1>|
          <exp(-I*k1) + m1, exp(-I*phi)*(m2 + exp(I*k2)), 0, 0>|
          <exp(-I*k2) + m2, exp(I*k1) + m1, 0, 0>
     >;

A := Matrix(4, 4, {(1, 1) = 0, (1, 2) = 0, (1, 3) = exp(-I*k1)+m1, (1, 4) = exp(-I*k2)+m2, (2, 1) = 0, (2, 2) = 0, (2, 3) = exp(-I*phi)*(exp(I*k2)+m2), (2, 4) = exp(I*k1)+m1, (3, 1) = exp(I*k1)+m1, (3, 2) = exp(I*phi)*(exp(-I*k2)+m2), (3, 3) = 0, (3, 4) = 0, (4, 1) = exp(I*k2)+m2, (4, 2) = exp(-I*k1)+m1, (4, 3) = 0, (4, 4) = 0})

Under the assumptions that the parameters are real, the Matrix is Hermitian and so must have 4 eigenvectors

simplify(A-A^%H);

Matrix([[0, 0, 0, 0], [0, 0, 0, 0], [0, 0, 0, 0], [0, 0, 0, 0]])

If we specifiy phi=Pi, we get the OP's error

evals,evecs:=LinearAlgebra:-Eigenvectors(eval(A,phi=Pi)):

Error, (in LinearAlgebra:-Eigenvectors) multiplicity mismatch

If we leave phi unspecified, then we don't get the error message, and get 4 eigenvectors

evals,evecs:=LinearAlgebra:-Eigenvectors(A):
nops(evals),nops(evecs);  #nops always reterns 3, as Carl points out
numelems(evals),numelems(evecs);

3, 3

4, 16

Now specify phi=Pi. Works for the eigenvalues, but not for the eigenvectors. Perhaps some manipulation could improve this, but I'm not sure

evals2:=eval(evals,phi=Pi);
eval(evecs,phi=Pi);

evals2 := Vector(4, {(1) = (2+m1^2+m2^2+2*m1*cos(k1)+2*m2*cos(k2))^(1/2), (2) = -(2+m1^2+m2^2+2*m1*cos(k1)+2*m2*cos(k2))^(1/2), (3) = (2+m1^2+m2^2+2*m1*cos(k1)+2*m2*cos(k2))^(1/2), (4) = -(2+m1^2+m2^2+2*m1*cos(k1)+2*m2*cos(k2))^(1/2)})

Error, numeric exception: division by zero






Download Hermitian2.mw

When legend is a list there need to be multiple curves, but you had one curve with 3 points. One way to do this is:

display(pointplot([28,.6481496576],color=blue),pointplot([28,.648149657615473],color=orange),pointplot([28,.6512873548],color=red),style=point,labels = ["k", "y(k)"], legend = ["10-digit precision", "15-digit precision", "Floating-point iteration"] ,legendstyle = [font = ["HELVETICA", 9], location = right]);




Not entirely certain I know what you want, but this may be a start.

[Edit: I changed pi (just a symbol) to Pi (the circle constant thing)]

At the beginning I define i to be sqrt(-1) as you want and D to be a regular variable rather than the differential operator.

Maple gives the answer as a sum over roots of a quartic polynomial. To get a simpler formula, you will need to give values to some variables or parhaps tell Maple their signs (using assuming)

Download Linear_System.mw

As well as Joe's corrections, you need to assign to y (y:=1).


r:=proc(x)
    local y;
    if (x=1)
    then
    y:=1;
    else
        y:=0;
    end if;
    return y
    end proc;


proc (x) local y; if x = 1 then y := 1 else y := 0 end if; return y end proc

h:=proc(x);
    if (x= infinity)
    then
    return 1 ;
    else
        return 0;
        end if;
    end proc

proc (x) if x = infinity then return 1 else return 0 end if end proc

r(1);r(2);

1

0

h(1);h(infinity);

0

1






Download ww.mw



I suspect you want gcdex(x^9-a, b*x^6-c, x); but the answer is 1. You may need to specify the numerical value of more of the coefficients.

Try

T := unapply('fsolve'(m(t, c) = -1, t = 0 .. (1/2)*Pi), c, numeric);

In general use unapply to make functions from expressions earlier in the worksheet. The numeric option means that plot and other functions evaluated with a symbolic value will not throw an error.

So the constant _C3 means another condition is required. Presumably you want the solution to drop off at y=infinity.

pdetest suggests your solution does not solve the pde.


Download pde.mw

Use := to assign the right-hand side to the left. Some other issues also:

v:= <1 |1| 0>;
w:=<1,1,0>;
M:=<1, 2, 3; 5, 4, 3; 7, 9, 0>;
c:=v.M;
d:=M.w;

v := Vector[row](3, {(1) = 1, (2) = 1, (3) = 0})

w := Vector(3, {(1) = 1, (2) = 1, (3) = 0})

M := Matrix(3, 3, {(1, 1) = 1, (1, 2) = 2, (1, 3) = 3, (2, 1) = 5, (2, 2) = 4, (2, 3) = 3, (3, 1) = 7, (3, 2) = 9, (3, 3) = 0})

c := Vector[row](3, {(1) = 6, (2) = 6, (3) = 6})

d := Vector(3, {(1) = 3, (2) = 9, (3) = 16})






Download vectors.mw

Try entering in 1D Maple input, e.g. at a > prompt use ctrl-M then `&le;`

You will see that `&le;` is rendered as less-than-or-equals, as it would be in HTML.

Changes in red.


 RK2skritt:=proc(FR::procedure,xo,yo,vxo,vyo,h)
 local x, y, vx, vy, r, kx1, kx2, kx3, kx4, ky1, ky2, ky3, ky4, lx1, lx2, lx3, lx4, ly1, ly2, ly3, ly4, tmp;
 r:=sqrt(xo*xo+yo*yo);
 tmp:=-(h*FR(r))/(r);
 lx1:=h*vxo;
 ly1:=h*vyo;
 kx1:=tmp*xo;
 ky1:=tmp*yo;
 lx2:=h*(vxo+0.5*kx1);
 ly2:=h*(vyo+0.5*ky1);
 r:=sqrt((xo+0.5*lx1)^(2)+(yo+0.5*ly1)^(2));
 tmp:=-(h*FR(r))/(r);
 kx2:=tmp*(xo+0.5*lx1);
 ky2:=tmp*(yo+0.5*ly1);
 lx3:=h*(vxo+0.5*kx2);
 ly3:=h*(vyo+0.5*ky2);
 r:=sqrt((xo+0.5*lx2)^(2)+(yo+0.5*ly2)^(2));
 tmp:=-(h*FR(r))/(r);
 kx3:=tmp*(xo+0.5*lx2);
 ky3:=tmp*(yo+0.5*ly2);
 lx4:=h*(vxo+kx3);
 ly4:=h*(vyo+ky3);
 r:=sqrt((xo+lx3)^(2)+(yo+ly3)^(2));
 tmp:=-(h*FR(r))/(r);
 kx4:=tmp*(xo+lx3);
 ky4:=tmp*(yo+ly3);  #edit - one more here
 x:=xo+(lx1+2*lx2+2*lx3+lx4)/(6);
 y:=yo+(ly1+2*ly2+2*ly3+ly4)/(6);
 vx:=vxo+(kx1+2*kx2+2*kx3+kx4)/(6);
 vy:=vyo+(ky1+2*ky2+2*ky3+ky4)/(6);
 [x,y,vx,vy]; end proc:





Download proc.mw

There is a missing *. The differentiation works in Maple 2017.


Download Diff.mw





restart

Case 1

de1:=diff(U(x),x,x)=0;
bc1:=U(0)=10,U(L)=20;
ans1:=dsolve({de1,bc1},U(x));

diff(diff(U(x), x), x) = 0

U(0) = 10, U(L) = 20

U(x) = 10*x/L+10

Case 2

de2:=diff(U(x),x,x)=-x^2;
bc2:=U(0)=T,D(U)(L)=0;
ans2:=dsolve({de2,bc2},U(x));

diff(diff(U(x), x), x) = -x^2

U(0) = T, (D(U))(L) = 0

U(x) = -(1/12)*x^4+(1/3)*L^3*x+T








Download rod.mw
