Question: How do I solve two PDEs together while they are not simple?

Ys := 70*10^9: # Young's Modulus structure

Yp := 11.1*10^10: # Young's Modulus pieazo

ha := -0.00125: # Position

hb := 0.001: # Position

hc := 0.0015: # Position

d31 := -180*10^(-12): # Piezoelectric constant

b := 0.01: #Width of the beam

tb := 0.002:

epsilon33 := 15.92*10^(-9):

hp :=0.00025: # Position

hpc := 0.00125: # Position

YI := b*(Ys*(hb^3- ha^3)+Yp*(hc^3-hb^3))/3: # Bending stiffness of the composit cross section

cs := 0.564: # The equivqlent coefficient of strain rate damping

ca := 0: # Viscous air damping coefficient

Ibeam := (b * tb^3 )/12: # The equivalent moment of inertia

m := 0.101: # Mass of the structure

upsilon := - Yp*d31*b*(hc^2-hb^2)/(2*hp): # Coupling term

lb := 0.57:# Length of the structure (Cantilever Beam)

lp := 0.05:# Length of the Piezoelectric

R:= 10000: # Shunted resistor

Electrical circuit equation

fn := 3.8:# Direct Excitation frequency;

wb(x,t) := 0.01*sin(fn*2*Pi*t):#Direct Excitation;

plot(wb(x,t),t = 0 .. 0.25*Pi,labels = [t,wb], labeldirections = ["horizontal", "vertical"], labelfont = ["HELVETICA", 15], linestyle = [longdash], axesfont = ["HELVETICA", "ROMAN", 10], legendstyle = [font = ["HELVETICA", 10], location = right],color = black);

FunctionAdvisor(definition, Dirac(n,x));

PDE2 := YI*diff(w(x, t),$(x, 4))+ cs*Ibeam*diff(w(x, t),$(x, 4))*diff(w(x, t), t)+ ca* diff(w(x, t), t) + m * diff(w(x, t),$(t, 2))+ upsilon*v(t)*(Dirac(1,x) -Dirac(1,x-lp) ) =-m*diff(wb(x, t),$(t, 2))-ca*diff(wb(x, t), t);#PDE

tmax := 0.3:

xmin := 0:

xmax := lb:

N := 20:#NUMBER OF NODE POINT

bc1 := dw(xmin, t) = 0:

bc2 := dw(xmax, t) = 0:

bc3 := w(xmin, t) = 0:

ic1 := wl(x, 0) = 0:
