Here is one way to handle your example, if your goal is to regain the original factored form.

ee := (sqrt(A+B)*x+sqrt(7-K)*y)^2;

((A+B)^(1/2)*x+(7-K)^(1/2)*y)^2

ff := expand(ee)

x^2*A+x^2*B+2*(A+B)^(1/2)*x*(7-K)^(1/2)*y-y^2*K+7*y^2

simplify(Student:-Precalculus:-CompleteSquare(ff));

((A+B)^(1/2)*x+(7-K)^(1/2)*y)^2


Download Ronan_simp_ex.mw

I personally like to see intercepts, and they can also be utilized here.

Also, I think that it's instructive to programmatically construct the equations from the Matrix/Vector data, if you've already shown such.

And this can get rid of implicitplot, which is a computationally inefficient hammer here.

restart

with(plots); with(plottools)


Define the matrix of coefficients and the vector of constants

A := Matrix([[1, 1], [12, 16]]); b := Vector([10, 136])

Matrix(2, 2, {(1, 1) = 1, (1, 2) = 1, (2, 1) = 12, (2, 2) = 16})

Vector[column](%id = 36893628725706251068)


Solve the linear system

sol := LinearAlgebra:-LinearSolve(A, b)

Vector[column](%id = 36893628725706240356)

eqs := Equate(A.`<,>`(x, y), b)

[x+y = 10, 12*x+16*y = 136]

eqs := `~`[isolate](eqs, y)

[y = 10-x, y = 17/2-(3/4)*x]


Compute x-intercepts

X1, X2 := `~`[solve](eval(eqs, y = 0))[]

10, 34/3


Compute y-intercepts

Y1, Y2 := `~`[solve](eval(eqs, x = 0))[]

10, 17/2

display(line([0, Y1], [X1, 0], color = red), line([0, Y2], [X2, 0], color = blue), pointplot([sol], symbol = circle, symbolsize = 12))

display(plot(rhs(eqs[1]), x = min(0, X1) .. max(0, X1), color = red, adaptive = false, numpoints = 2), plot(rhs(eqs[2]), x = min(0, X2) .. max(0, X2), color = blue, adaptive = false, numpoints = 2), pointplot([sol], symbol = circle, symbolsize = 12))



Download linear_systems_icepts.mw

I could also have made the above two lines using a single call to the plot command. But I wanted to see them from intercept-to-intercept.

There are so many ways to do all this, including the construction of the equations.

The 3D case can be handled similarly.

The command plottools:-getdata can extract data from these, just like for usual 2D plots of curves.

restart;

plots:-setoptions(size=[600,200]);

pd_numeric:=(D[2,2])(u_numeric)(x,t)+(D[1,1,1,1])(u_numeric)(x,t)-0*h(x,t)=0:
bc_numeric[1]:=u_numeric(0,t)=0:
bc_numeric[2]:=(u_numeric)(1,t)=0:
bc_numeric[3]:=D[1,1](u_numeric)(0,t)=0:
bc_numeric[4]:=D[1](u_numeric)(1,t)=0:
ic_numeric[1]:=u_numeric(x,0)=0.1*x*(x-1)^2:
ic_numeric[2]:=D[2](u_numeric)(x,0)=0:

sol:=pdsolve(pd_numeric, {seq(bc_numeric[i], i=1..4),
             seq(ic_numeric[i],i=1..2)}, u_numeric(x,t), time=t,
             range=0..1, numeric, spacestep=1/2000, timestep=1/2000):

sol:-plot(t=1, labels=[x,u_numeric]);

sol:-value(t=0.5)(0.75);
eval(u_numeric(x, t),%);

[x = .75, t = .5, u_numeric(x, t) = HFloat(-0.0015866001714942412)]

HFloat(-0.0015866001714942412)

UT[0.5] := eval(u_numeric(x, t),
               sol:-value(t=0.5, output=listprocedure)):

UT[0.5](0.75);
UT[0.5](0.25);
UT[0.5](1.0);

HFloat(-0.0015866001714942412)

HFloat(0.003952648473246894)

HFloat(0.0)

# 100 data points
str := time[real]():
sol:-plot(x=0.75, t=0..2, labels=[t,u_numeric], numpoints=100);
time[real]()-str;
op([1,1,2],%%);

5.979

1 .. 100, 1 .. 2

# 4001 data points, it seems
str := time[real]():
sol:-plot(x=0.75, t=0..2, labels=[t,u_numeric]);
time[real]()-str;
op([1,1,2],%%);

6.467

1 .. 4001, 1 .. 2

UXT := unapply('eval(u_numeric(:-x,:-t),sol:-value(:-t=T)(X))',X,T,numeric):

UXT(0.75, 0.5);
UXT(0.25, 0.5);
UXT(1.0, 0.5);

HFloat(-0.0015866001714942412)

HFloat(0.003952648473246894)

HFloat(0.0)

UXT(0.75, 0.2);
UXT(0.25, 0.2);
UXT(1.0, 0.2);

HFloat(-0.004525893648234543)

HFloat(-0.013666119932391071)

HFloat(0.0)

# less efficient, also 100 data points
str := time[real]():
plot(UXT(0.75,t), t=0..2, adaptive=false, numpoints=100,
     color=red, labels=[t,u_numeric]);
time[real]()-str;

6.245

# less efficient, also 4001 data points
str := time[real]():
plot(UXT(0.75,t), t=0..2, adaptive=false, numpoints=4001,
     color=red, labels=[t,u_numeric]);
time[real]()-str;

7.372

# an amusing way, also 100 data points
str := time[real]():
plot(<<seq(0..2,numelems=100)>|Vector[column](op([1,3],sol:-plot3d(t=0..2,x=0..0.75, grid=[2,100]))[2,..])>,
     color=red, labels=[t,u_numeric]);
time[real]()-str;

6.009

# an amusing way, also 4001 data points
str := time[real]():
plot(<<seq(0..2,numelems=4001)>|Vector[column](op([1,3],sol:-plot3d(t=0..2,x=0..0.75, grid=[2,4001]))[2,..])>,
     color=red, labels=[t,u_numeric]);
time[real]()-str;

6.535

Download pds_num_ex1.mw

You've mistakenly indexed things.

For example you have,
   Theta(t)[q]
instead of,
   Theta[q](t)

And similarly you have,
   diff(Theta(t),t)[q]
instead of,
   diff(Theta[q](t),t)

And so on. Note that Theta[1], Theta[2], Theta[3] are all names in Maple. They are indexed names, but can be used for function calls like Theta[1](t), etc.

And the initial conditions are done incorrectly. You can replace with D syntax to express the derivatives evaluated at 0.

I didn't wait for a symbolic solution. But a numeric solution using default method follows.

mrpicky_DE_syntax.mw

Check the edits for correctness.

The command,
   plottools:-getdata(p1)[3]
will return the 2-column Matrix of the data in the p1 plot.

You can then use the ExportMatrix command as one way to export it to a file with Excel-compatible format.

For example,

   ExportMatrix( "foo.xls", plottools:-getdata(p1)[3], target=Excel )

You should use add instead of sum there.

Also, if the Vector is assigned to m then utilize that name, not L.

In the current Maple version you could just call it as add(m).

For example,

m := Vector[column](3, [2, 1, c]):

add(m);

3+c

add(m[k], k=1..3) ;

3+c


Download Vadd.mw

The reason is that m[k] throws an error upon evaluation, where k is just an unassigned name. and m is a Matrix/Vector/Array.

The sum command will get its arguments (such as the reference m[k]) evaluated up front, which is Maple's usual evaluation rules for procedure calls. In contrast, the add command has special evaluation rules which delay the evaluation of first argument m[k] until k actually takes on the numeric values.

By the way, the following magenta error message is actually a URL. In my Maple clicking on it goes to this link, which contains an example and explanation, and the workaround using add. (note: Not all error message URLs go somewhere useful.)

m:=Vector[column](3, [1, 1, 1]);
sum(m[k], k = 1 .. 3) ;

Vector(3, {(1) = 1, (2) = 1, (3) = 1})

Error, bad index into Vector

Download Vsum_err.mw

Do you mean that you want the data in the userinfo message shown in the second attachment shown below?

In Maple 2020 it could be done programmatically as,

kernelopts(version);

`Maple 2020.2, X86 64 LINUX, Nov 11 2020, Build ID 1502365`

eval(`plots/coordRanges`[ellipsoidal],[_a=1,_b=1/2,_c=1/3]);

[[3], [3/4], [1/4], [1 .. 5, 1/2 .. 1, 0 .. 1/2], [0 .. 5, 0 .. 5, 0 .. 5]]


Download coordplot3d_ex1_M2020.mw


And in Maple 2024.0 in can be done as,

restart;

`plots/coordRanges3`[ellipsoidal](1,1/2,1/3);

[[3], [3/4], [1/4], [1 .. 5, 1/2 .. 1, 0 .. 1/2], [0 .. 5, 0 .. 5, 0 .. 5]]



infolevel[coordplot3d]:=2:

plots:-coordplot3d(ellipsoidal, size=[300,300]);

plots/coordplot3d: u const values: [3]

plots/coordplot3d: v const values: [3/4]

plots/coordplot3d: w const values: [1/4]

plots/coordplot3d: u range: 1 .. 5

plots/coordplot3d: v range: 1/2 .. 1

plots/coordplot3d: w range: 0 .. 1/2

plots/coordplot3d: view: [0 .. 5 0 .. 5 0 .. 5]

Download coordplot3d_ex1.mw

Issuing,
   showstat(plots:-coordplot3d);
can lead one to,
   showstat(`plots/coordplot3d`);

I'm not sure how much timing performance matters to you. If you only need a final plot then you might choose say 1e-4 or 1e-5 as target accuracy for that, and work backwards if reducing earlier working precision helps with performance. I don't know whether you need high accuracy, or faster timing.

Perhaps the following attachment has some useful bits. The re-usable procedures make it more straightforward to compute for arbitrary m-mu pairs. The plot3d command is invoked with a variable range formula (to respect a condition like mu^2>m, etc).

Your list N has about 50 possible values for mu. The "edge" that the 3d point-plot exhibits is coarse and uneven because the granularity of N doesn't allow all these found points to represent the same degree of closeness to the boundary of the inequality. The points themseleves directly provide only a very rough approximation.

But a style=surfacecontour 3D plot can get you a smoother boundary, with an even closeness for each m value. Naturally you could use another contour value, of your choice of boundary height.

And these procedures could be adjusted. A single dsolve call with two "parameters" might be used. Or an outer procedure might accept just one argument (m value), and then do root-finding (bisection or careful NextZero) for optimal mu value at boundary height. Etc.

Or you might interpolate your grid data programmatically, and then poll arbitarily or (with care for nested precision issues) find the boundary or implicit-plot; I didn't do so, but could it you'd like.

LoopError_acc.mw

Is this what you're trying to do: raise the 2D points in p1 to the vertical height (3D) given by the phi formula?

(This makes the 2D and 3D contour values match exactly, as well as allows the 3D plot to actually contain its data -- stored, and maybe a few other niceties of the 2D command.)

Help_3D_view_ac.mw

Using your 2D contour plot and its colors,

The following attachment works for me using Maple 18.02, if I first increase the Java Heap size. I made it 2048 instead of default 512.

It takes about 45 seconds for my machine to actually save the animated .gif file (before that it appears empty).

Cuve_1X_Anim_with_Circls_Seq_ac1.mw

I only made and exported one single animated .gif file from the worksheet. I didn't test producing more, in the same worksheet session.

But the Resize did in fact work, and the exported .gif file showed that.

Here's one way to handle an example like that.

The steps are to select the indices in which you're interested, and then to map table-lookup across those indices, and then take the min of the resulting values.

f := rand(1..100):

T := table([seq([R||i=f(),a||i=f(),b||i=f(),b||i=f()][], i=1..3)]);

table( [( R2 ) = 98, ( a1 ) = 45, ( R3 ) = 38, ( R1 ) = 93, ( a2 ) = 59, ( b3 ) = 96, ( a3 ) = 69, ( b2 ) = 100, ( b1 ) = 6 ] )



min(map[2](`?[]`,T,select(hastype,[indices(T)],suffixed(a))));

45





The steps of that are,



select(hastype,[indices(T)],suffixed(a));

[[a1], [a2], [a3]]

map[2](`?[]`,T,%)

[45, 59, 69]

min(%);

45


Download anthr_tab_sel2.mw

It's not clear whether you're asking about how to programmatically determine the version of Maple in which code gets run, or whether you're asking about how to determine the version in which a worksheet was last saved.

I'm guessing it's the former.

The command kernelopts(version) returns a name that contains the version number. That could be converted to a string.

You can chop up that string to take only a particular portion, eg.

str:=convert(kernelopts(version),string);

   str := "Maple 2018.2, X86 64 LINUX, Nov 16 2018, Build ID 1362973"

str[7 .. StringTools:-Search(".",str)-1];

            "2018"

You could use either InertForm:-Display or (undocumented) Typesetting:-Typeset for this.

restart;



R := 10:



plots:-textplot([600,-Pi*floor(R)*ln(R)-0.01,
                 InertForm:-Display(-Pi*floor(r)*ln(r)),
                 font=[Helvitica,bold,14]],labels=[T," "]);

plots:-textplot([600,-Pi*floor(R)*ln(R)-0.01,
                 Typesetting:-Typeset(-Pi*floor(r)*ln(r)),
                 font=[Helvitica,bold,14]],labels=[T," "]);


Download textplot_ts_ex1.mw

Your given example can be handled by the define command.

restart;



define(T,T(a::nonunit(algebraic)+b::nonunit(algebraic))=T(a)+T(b),
         T(a::nonunit(algebraic)*x^n::integer)=a*T(x^n),
         'conditional'(T(a::anything)=a*T(1),
                       _type(a,And(Not(identical(1)),freeof(x)))));



T(alpha__1*x^2*y+alpha__2*x^4*t+alpha__3*t*y);

t*alpha__2*T(x^4)+y*alpha__1*T(x^2)+alpha__3*t*y*T(1)


Download define_ex.mw

Is this the kind of effect you're after?

Note that there's no need for any isolation/resubstitution to attain the first target form: collect is enough.

Note a sign difference in the second term of the target form.

The same algsubs result can also be obtained directly from the original expression (expanded), without the intermediate target form.

restart;

expr := 3*G*(`&Delta;&gamma;`*H - `&sigma;y`(`&Delta;&gamma;`) + q)/(-q + `&sigma;y`(`&Delta;&gamma;`))^2;

3*G*(`&Delta;&gamma;`*H-`&sigma;y`(`&Delta;&gamma;`)+q)/(-q+`&sigma;y`(`&Delta;&gamma;`))^2

targ := collect(expr,H,simplify);

3*G*`&Delta;&gamma;`*H/(-q+`&sigma;y`(`&Delta;&gamma;`))^2-3*G/(-q+`&sigma;y`(`&Delta;&gamma;`))

RR := G*`&Delta;&gamma;`=y/3*(q - `&sigma;y`(`&Delta;&gamma;`));

G*`&Delta;&gamma;` = (1/3)*y*(-`&sigma;y`(`&Delta;&gamma;`)+q)

algsubs(RR, targ);

-3*G/(-q+`&sigma;y`(`&Delta;&gamma;`))-H*y/(-q+`&sigma;y`(`&Delta;&gamma;`))

ans := simplify(%);

(H*y+3*G)/(-`&sigma;y`(`&Delta;&gamma;`)+q)

algsubs(RR, expand(expr));

-3*G/(-q+`&sigma;y`(`&Delta;&gamma;`))-H*y/(-q+`&sigma;y`(`&Delta;&gamma;`))

simplify(%);

(H*y+3*G)/(-`&sigma;y`(`&Delta;&gamma;`)+q)

sort(ans, q);

(H*y+3*G)/(q-`&sigma;y`(`&Delta;&gamma;`))


Download ceeeb_ex.mw

[edit] Even though your intermediate target form is not necessary to achieve the algsubs result, it could also be obtained with,

   convert(expr,parfrac,q);
   sort(%,order=plex(H,q));   # optional
